LED Displays for Buses and Public Transport – BS Series

The BS Series consists of professional LED displays for buses, minibuses, special vehicles, and public transport systems. The displays are designed for passenger information systems, showing route numbers, destinations, stop names, and text messages.

Each bus LED display can be customized to the customer’s individual requirements, available installation space, and the communication method used by the vehicle system.

LED Displays for Buses – Available Sizes

The dimensions of BS Series displays can be customized according to the specific project requirements.

Example models:

• BS205 – 32 × 160 cm
• BS101 – 16 × 32 cm
• BS103 – 16 × 96 cm

Other sizes can also be manufactured to suit installation at the front, rear, side, or inside the vehicle.

Pixel Pitch P10, P6.66 and P5

LED displays for transport applications are available in various pixel pitch configurations:

• 10 mm pixel pitch – P10
• 6.66 mm pixel pitch – P6.66
• 5 mm pixel pitch – P5

Choosing the appropriate pixel pitch ensures optimal passenger information readability, suitable resolution, and good visibility from the required viewing distance.

A smaller pixel pitch provides a higher resolution while maintaining the same external display dimensions.

LED Display Control and Open Communication Protocol

BS Series displays can be equipped with controllers supporting an open communication protocol.

This allows integration with:

• passenger information systems,
• onboard vehicle computers,
• fleet management systems,
• customer software,
• custom-developed control applications.

This solution enables vehicle manufacturers, system integrators, and transport operators to adapt the data transmission method to their own system requirements.

LAN and RJ45 Communication

Depending on the configuration, the displays can support communication via:

• LAN
• RJ45 connector
• controller communication interface
• dedicated data transmission protocol

This enables fast transmission and updating of information displayed on the LED screen.

The display can show, among other things:

• bus route number,
• destination,
• final stop name,
• next stop information,
• passenger announcements,
• technical and operational information,
• any content generated by the vehicle system.

12 V and 24 V LED Displays for Vehicles

BS Series bus displays can be adapted to electrical installations commonly used in vehicles.

Available power supply options:

• 12 V DC
• 24 V DC

Depending on the vehicle installation, suitable DC voltage converters are used to ensure stable power supply and reliable display operation.

Durable Powder-Coated Housing

LED displays for transport applications are manufactured in robust housings designed for operation in vehicles.

Metal components are powder coated, providing:

• an aesthetic finish,
• increased resistance to mechanical damage,
• improved durability during intensive use,
• long-lasting construction,
• the possibility of matching the housing colour to the vehicle interior or bodywork.

Dedicated LED Display Mounting Brackets

We can provide dedicated mounting brackets tailored to the specific vehicle model and installation location.

This makes BS Series displays suitable both for new vehicles and for modernisation of existing buses and passenger information systems.

Key Advantages of BS Series LED Displays

• custom LED display dimensions,
• suitable for buses, minibuses, and special-purpose vehicles,
• pixel pitch P10, P6.66 or P5,
• excellent readability of displayed information,
• integration with existing vehicle systems,
• open communication protocol,
• compatibility with customer-developed software,
• LAN / RJ45 communication,
• 12 V or 24 V power supply,
• dedicated voltage converters,
• dedicated mounting brackets,
• durable powder-coated housing,
• customised technical configuration,
• suitable for both single vehicles and entire fleets.

Passenger Information Displays Tailored to Your Project

The BS Series can be used as a front destination display, side display, rear display, or as part of an internal passenger information system.

We can customise the dimensions, resolution, control method, power supply, and mounting components according to the requirements of a specific project.

Looking for an LED display for a bus, minibus, or other vehicle? Contact us and send us the required dimensions, control method, and supply voltage. We will prepare a solution tailored to your system.
