Graphic single colour


Main features of GL GRAPHIC displays.



Resolution - 20 mm pixel pitch. Resolution - 20 mm pixel pitch. High luminosity of LEDs. Manual and  automatic brightnes control.

High luminosity of LEDs. Manual and

automatic brightnes control.

Mask with a roofing for each diode!

Mask with a roofing for each diode!

 Energy-saving. Energy-saving.
Displaying information in one many lines. Displaying information in one many lines.  Numerous text and graphics effects for  each display region.

Numerous text and graphics effects for

each display region.

Animated texts,graphics and   backgrounds.

Animated texts,graphics and

backgrounds.

 Include clock , calendar, thermometer,  and humidity sensor!

Include clock , calendar, thermometer,

and humidity sensor!

Panel boarder moving clockwise,  anticlockwise,flashing, and static!

Panel boarder moving clockwise,

anticlockwise,flashing, and static!

 Turns ON/OFF at a definite time. Turns ON/OFF at a definite time.
Modular Construction,Enlargeable.  Frontal service!

Modular Construction,Enlargeable.

Frontal service!

 Weather proof. Weather proof.
Polski producent

Product of POLAND.

 24 months warranty. 24 months warranty.

Other Features of  GL GRAPHIC displays.



Computer-controlled via LAN as a   standard or Wi-Fi as a option.

Computer-controlled via LAN as a

standard or Wi-Fi as a option.

Capacious FLASH memory can  hold up to 5 hour-long projects.

Capacious FLASH memory can

hold up to 5 hour-long projects.

Data input from a flash drive. Data input from a flash drive.  Use all text fonts installed on your  computer.

Use all text fonts installed on your

computer.

The ability to control from any  place in the world via the internet.

The ability to control from any

place in the world via the internet.

komunikaty na godziny i określone dni tygodnia  Time-definite and day-definite

displaying of messages.

Remote control. Remote control. Increased durability. Increased durability.








Functions


Advantages of GL GRAPHIC DISPLAYS

 Readability of displayed content.

The high density of LEDs in conjunction with image shading and high brightness ensures high quality displayed text and images. Thanks to this, presented content is clear and readable even from a long distance.

Large opportunities.

Numerous effects, with the ability to display information even in a few lines or regions, in any language, animated text, graphics and backgrounds, dynamic and static border of display provide significant opportunities to display information. The total number of possible combinations is very large. As a result, advertising is not boring, it's constantly changing and it's dynamic so attracts the attention of spectators. The software allows you to load the selected image and video file formats.

Modular casing.

The units are built as a modular constructions, which allows to obtain the desired display format. You can expand the device or divide the big screen on several small ones, for ease of transport and installation.

Attractive features.

In addition to the text and graphics information, on the boards you can also display temperature, date  and  time.  Such  data  are  attractive  because  they  strongly  pay  attention, and  people interested in these parameters waiting for the desired information read the advertisement. The board has an automatic switching on and off with preset times so that can optimize more the cost of operating related to the consumption of electricity. Other advantages of displays is the ability  to  set  a  specific  brightness  at  predetermined  time,  or  optional  automatic  brightness control based on measurements from the sensor. Without a doubt, great opportunities is also the option to display selected information at specified times. This opens up the perspective for users of our devices to create daily or hourly informational campaigns and promotional activities. You can also display other information on business hours, and others out of the opening hours. When working  with  designing  advertising  useful  functions  are  also  variable  speed  effects,  adjust  the stop time and the appropriate location of texts.

Quality of devices.

Offered  devices  are  high  quality.  They  are  made  from  lightweight  and  durable  materials  for optimum  durability  and  resistance  to  weather  conditions.  The  LEDs  are  protected  with  plastic masks with protective roofs on each diode, which provide protection against mechanical damage and improve the contrast of the display. All tables are CE certified.

Several ways to control.

LAN - as standard displays have a power cord with plug RJ45. With it, you can connect the device directly to the computer or turn it to the LAN, and then send the advertisement. If you connect the device to the network, it is possible to program device from any computer on the network.

Wi-Fi - Another way of communications is connection through Wi-Fi. With this method of communication you can program the display wirelessly via Wi-Fi. Display generates its own Wi-Fi network to which you must connect to be able uploading data to display. By default, the network is protected by a password. It is also possible to configure the Wi-Fi  to automatically connect to another network within its range, e.g. to an existing network in the company, which will enable the management screen from any computer on the local network.

USB Flash Drive - Advertising is preparing in the program on your computer. Then export it to a file on your memory stick. Connect the USB stick with a project file that contains the ad then connect to the USB port on the display's cable. After plugging the media to the USB display, driver reads the data from the flash drive and saves them in the internal memory of the display. After copying the project, you can unplug the flash drive from the USB socket and close the connector.

IR remote control - Simple to control the operation of the display can be realized using the IR remote control. In contrast to previous methods of remote control has limited functionality and short range. With its use, you can turn on and off board, adjust the brightness and switch to specific projects in the spot.

Made in Poland, Made in EU.

The devices are designed and manufactured in Poland. Choosing Polish brand You support our technical thought and work  in  Poland and  European  Union. Our products are appreciated all over Europe and the World, because  of their quality, functionality and capabilities. Easy access to spare parts, fast service, the opportunity of support even after the warranty period are undoubted
advantages and the reason of selection the Polish unit.

Technical support.

Choosing devices from our offer you gain access to the phone and e-mail support, which works for support of our customers.

Display models

GRAPHIC DISPLAYS GL
height 32 cm, height 48 cm
Model Dimensions Resolution Weight Average
power
consumption
GL202 64 x 32 cm 32 x 16 px 6 kg 8 W
GL203 96 x 32 cm 48 x 16 px 8 kg 12 W
GL204 128 x 32 cm 64 x 16 px 11 kg 16 W
GL205 160 x 32 cm 80 x 16 px 14 kg 20 W
GL206 192 x 32 cm 96 x 16 px 17 kg 24 W
GL207 224 x 32 cm 112 x 16 px 20 kg 28 W
GL208 256 x 32 cm 128 x 16 px 22 kg 32 W
GL209 288 x 32 cm 144 x 16 px 25 kg 36 W
GL210 320 x 32 cm 160 x 16 px 28 kg 40 W
GL211 352 x 32 cm 176 x 16 px 31 kg 44 W
GL212 384 x 32 cm 192 x 16 px 34 kg 48 W
GL302 64 x 48 cm 32 x 24 px 8 kg 12 W
GL303 96 x 48 cm 48 x 24 px 13 kg 18 W
GL304 128 x 48 cm 64 x 24 px 17 kg 24 W
GL305 160 x 48 cm 80 x 24 px 21 kg 30 W
GL306 192 x 48 cm 96 x 24 px 25 kg 36 W
GL307 224 x 48 cm 112 x 24 px 29 kg 42 W
GL308 256 x 48 cm 128 x 24 px 34 kg 48 W
GL309 288 x 48 cm 144 x 24 px 38 kg 54 W
GL310 320 x 48 cm 160 x 24 px 42 kg 60 W
GL311 352 x 48 cm 176 x 24 px 46 kg 66 W
GL312 384 x 48 cm 192 x 24 px 50 kg 72 W
... ... ... ... ...



GRAPHIC DISPLAYS GL
height 64 cm, height 80 cm
Model Dimensions Resolution Weight

Average
power
consumption

GL402 64 x 64 cm 32 x 32 px 11 kg 16 W
GL403 96 x 64 cm 48 x 32 px 17 kg 24 W
GL404 128 x 64 cm 64 x 32 px 22 kg 32 W
GL405 160 x 64 cm 80 x 32 px 28 kg 40 W
GL406 192 x 64 cm 96 x 32 px 34 kg 48 W
GL407 224 x 64 cm 112 x 32 px 39 kg 56 W
GL408 256 x 64 cm 128 x 32 px 45 kg 64 W
GL409 288 x 64 cm 144 x 32 px 50 kg 72 W
GL410 320 x 64 cm 160 x 32 px 56 kg 80 W
GL411 352 x 64 cm 176 x 32 px 62 kg 88 W
GL412 384 x 64 cm 192 x 32 px 67 kg 96 W
GL503 96 x 80 cm 48 x 40 px 21 kg 30 W
GL504 128 x 80 cm 64 x 40 px 28 kg 40 W
GL505 160 x 80 cm 80 x 40 px 35 kg 50 W
GL506 192 x 80 cm 96 x 40 px 42 kg 60 W
GL507 224 x 80 cm 112 x 40 px 49 kg 70 W
GL508 256 x 80 cm 128 x 40 px 56 kg 80 W
GL509 288 x 80 cm 144 x 40 px 63 kg 90 W
GL510 320 x 80 cm 160 x 40 px 70 kg 100 W
GL511 352 x 80 cm 176 x 40 px 77 kg 110 W
GL512 384 x 80 cm 192 x 40 px 84 kg 120 W
GL513 416 x 80 cm 208 x 40 px 91 kg 130 W
... ... ... ... ...



GRAPHIC DISPLAYS GL
height 96 cm, height 112 cm
Model Dimensions Resolution Weight Average
power
consumption
GL603 96 x 96 cm 48 x 48 px 25 kg 36 W
GL604 128 x 96 cm 64 x 48 px 34 kg 48 W
GL605 160 x 96 cm 80 x 48 px 42 kg 60 W
GL606 192 x 96 cm 96 x 48 px 50 kg 72 W
GL607 224 x 96 cm 112 x 48 px 59 kg 84 W
GL608 256 x 96 cm 128 x 48 px 67 kg 96 W
GL609 288 x 96 cm 144 x 48 px 76 kg 108 W
GL610 320 x 96 cm 160 x 48 px 84 kg 120 W
GL611 352 x 96 cm 176 x 48 px 92 kg 132 W
GL612 384 x 96 cm 192 x 48 px 101 kg 144 W
GL703 96 x 112 cm 48 x 56 px 29 kg 42 W
GL704 128 x 112 cm 64 x 56 px 39 kg 56 W
GL705 160 x 112 cm 80 x 56 px 49 kg 70 W
GL706 192 x 112 cm 96 x 56 px 59 kg 84 W
GL707 224 x 112 cm 112 x 56 px 69 kg 98 W
GL708 256 x 112 cm 128 x 56 px 78 kg 112 W
GL709 288 x 112 cm 144 x 56 px 88 kg 126 W
GL710 320 x 112 cm 160 x 56 px 98 kg 140 W
GL711 352 x 112 cm 176 x 56 px 108 kg 154 W
GL712 384 x 112 cm 192 x 56 px 118 kg 168 W
... ... ... ... ...



GRAPHIC DISPLAYS GL
height 128 cm, height 144 cm
Model Dimensions Resolution Weight Average
power
consumption
GL803 96 x 128 cm 48 x 64 px 34 kg 48 W
GL804 128 x 128 cm 64 x 64 px 45 kg 64 W
GL805 160 x 128 cm 80 x 64 px 56 kg 80 W
GL806 192 x 128 cm 96 x 64 px 67 kg 96 W
GL807 224 x 128 cm 112 x 64 px 78 kg 112 W
GL808 256 x 128 cm 128 x 64 px 90 kg 128 W
GL809 288 x 128 cm 144 x 64 px 101 kg 144 W
GL810 320 x 128 cm 160 x 64 px 112 kg 160 W
GL811 352 x 128 cm 176 x 64 px 123 kg 176 W
GL812 384 x 128 cm 192 x 64 px 134 kg 192 W
GL903 96 x 144 cm 48 x 72 px 38 kg 54 W
GL904 128 x 144 cm 64 x 72 px 50 kg 72 W
GL905 160 x 144 cm 80 x 72 px 63 kg 90 W
GL906 192 x 144 cm 96 x 72 px 75 kg 108 W
GL907 224 x 144 cm 112 x 72 px 88 kg 126 W
GL908 256 x 144 cm 128 x 72 px 101 kg 144 W
GL909 288 x 144 cm 144 x 72 px 113 kg 162 W
GL910 320 x 144 cm 160 x 72 px 126 kg 180 W
GL911 352 x 144 cm 176 x 72 px 138 kg 198 W
GL912 384 x 144 cm 192 x 72 px 151 kg 216 W
... ... ... ... ...




Software to manage displays

With every devices, each customer receives the software to control the display. The software is compatible with any version of the Windows operating system (XP, Vista, 7, 8, 10, 32 bit, 64 bit).


Exampled technical drawing
